Voltage 3/N/PE/AC/50Hz/400V
• Suitable for winter operation down to -15°C outside temperature
• Antifreeze circulatory system with internal WAB
• Stainless steel lance quiver with anti-freeze water return to the WAB
• PLC to control the antifreeze circuit system with pressure relief
• Etronic I-Controls
• 10m HD-Hose DN08 - 315bar
• Shut-off pistol with low-pressure leakage
• Lance 900mm with nozzle protection
• Stainless steel flat jet nozzle 25°
• Water-Supply separation acc. DIN EN 1717 class 4
• Chemical supply in high-pressure Jet c/w Metering-valve
• Recommendation: Installation Kit - Automatic
• Hose reel with 20m HP hose - optional
Operating pressure 30-165bar/3-16,5MPa
Max. pressure 185bar/18,5MPa
Discharge capacity 300-1000l/h
Nozzle size 055
Heating capacity 30kW
Hot water capacity 30-80°C
Pump speed 1400rpm
Connected load 36,5kW/57,0A
Electrical protection 3x63A slow
Weight net/with package 292kg/309kg
Dimensions device/with package (LxWxH) 122x75,5x162,5cm/125x81,5x175,5cm
S
elf-supporting, robust, device-chassis made out of stainless-steel, suitable for floor installation, 20mm PU-sound and thermal insulation, thermostatic chassis electric
heating 80W, thermostatically and SPS controlled frost protection circuit system with frost protection water recirculation in the internal WAB 40ltr, reliable down to -15°C
outside temperature, stainless steel hot water boiler 65l capacity with preheating and buffering for immediate hot water use and hot water preparation in stand-by mode,
triplex-piston pump with brass pump head, nickel plated, high-performance ceramic piston, stainless-steel valves, leakage-return, Etronic I - controls: (start-stop system with
switch-off delay, total-switch-off after 20min, OPH-counter with service information, optical flame monitoring with photoelectric cell and fault indicator-light) 2 motors
system (independent of the direction of rotation) separately for H.P.-Pump and heating, unloader safety-valve c/w Infinitely variable pressure and quantity regulation, integrated diesel-tank 60l, separate space for 2x20l cleaning
